The Hydraulic Boom Cylinder Piston Seal is designed to seal the piston within a hydraulic boom cylinder, effectively containing hydraulic fluid and maintaining optimal pressure, this seal prevents leakage, which can compromise system efficiency and performance. By creating a tight barrier between the piston and cylinder wall, the seal ensures minimal fluid bypass, allowing hydraulic systems to operate reliably under varying loads and conditions. The design of the piston seal is required for its effectiveness, as it must withstand high pressures and frequent movement without compromising its sealing properties to ensure the longevity of hydraulic systems. Attributes: • Prevents contamination ingress. • Prevents hydraulic fluid leakage. • Resistance to extrusion. • High-pressure resistance. • Enhanced wear resistance. • Superior sealing integrity. Applications: The Hydraulic Boom Cylinder Piston Seal is used to ensure reliable sealing and pressure containment within the boom cylinder to optimize hydraulic system performance in diverse operating conditions.
Groove Diameter - B (+/- 0.0762 mm) (mm): 161.16 Bore Diameter (mm): 184.15 Seal Shape: Type 3 Oversize Dim: 0.030 Groove Width - A (+/- 0.0508 mm) (mm): 15.98
