A Hydraulic Cylinder Seal is designed to maintain a tight seal between the piston and cylinder bore, ensuring optimal hydraulic performance. When installed within a hydraulic cylinder, the seal is positioned between the piston and cylinder bore, forming a tight barrier to prevent hydraulic fluid from escaping. As the hydraulic system operates, the seal effectively maintains hydraulic pressure, allowing the cylinder to move smoothly and perform its intended function. By preventing fluid leakage, the seal helps preserve system integrity, prolonging the lifespan of hydraulic components and ensuring consistent performance of equipment. Attributes: • It has a groove diameter of 289.05milimeter. • Resilient to temperature variations. • Superior sealing performance. • Resistant to wear and tear. • Suitable for 0.76milimeter oversize bore. Applications: A Hydraulic Cylinder Seal is positioned at the piston rod end and cylinder bore, to ensure efficient fluid containment, preventing leakage, and maintaining hydraulic system integrity in equipment operations.
Groove Diameter - B (+/- 0.0762 mm) (mm): 289.05 Bore Diameter (mm): 317.50 Seal Shape: Type 3 Oversize Dim: 0.030 Groove Width - A (+/- 0.0508 mm) (mm): 17.53
