A Hydraulic Stick Cylinder is a hydraulic actuator that consists of a cylindrical barrel, a piston, and a rod. It is located on the machine's stick assembly, connecting it to the mainframe or the bucket linkage. It converts hydraulic fluid pressure into linear force and motion to perform excavation tasks. This cylinder is double-acting, meaning it can extend and retract based on the direction of the applied hydraulic pressure. Attributes: • Provides high force capabilities, allowing the stick to handle heavy loads • Buckling Safety Factor is 2.45:1 at 21600 kPa Applications: A Hydraulic Stick Cylinder transfers hydraulic pressure efficiently into linear force. It allows smooth, precise, and controlled extension and retraction of the stick, enabling efficient operation of attachments or implements.
MINI HYD EXCAVATOR 302.5C
