The Tilt Cylinder Rod is a robust, cylindrical metal shaft made of high-strength material. It serves as the main structural element in the tilt cylinder assembly, which is part of the hydraulic system. The rod extends and retracts within the hydraulic cylinder to adjust the angle of attachment tilt, allowing operators to manipulate the position of buckets, blades, or other implements mounted on the equipment. The primary function of the tilt cylinder rod is to translate hydraulic pressure into mechanical force, enabling the controlled tilting motion of equipment attachments. When pressurized hydraulic fluid enters the cylinder, it pushes against the piston connected to the rod, causing it to extend or retract. This movement adjusts the angle of the attachment, facilitating tasks such as digging, grading, or leveling. Attributes: • Designed to withstand loads and harsh operating conditions. • Precision-machined to ensure smooth movement within the cylinder, reducing friction and wear. • Treated to enhance corrosion resistance. Applications: The Tilt Cylinder Rod is situated within the tilt cylinder assembly, which is mounted on the frame of equipment to provide optimal leverage for controlling the tilt angle of attachments.
TRACK-TYPE TRACTOR D6M D6N
